The FT (final test) is a crucial step in IC manufacturing that ensures the quality and reliability of the final product. Our FT equipment is highly effective and precise and supports dual- and triple-temperature testing for enhanced production efficiency and product quality.

• Support ATC6.0 system
• Site: 16 Sites
• Temp: 50~130℃（Option 175℃）
• Contact Force: 480Kg（Option 640Kg）
• Cooling Method：Air Cooling System
• X-Y controllable pitch PnP module: Various product requirements are accommodated flexibly.
• Highly effective output: Up to 16K for enhanced production efficiency
• Expandable diversified optional features: Satisfy different application needs

• Site: 16 Sites
• Temp: 50~130℃（Option 175℃）
• Contact Force: 480Kg（Option 640Kg）
• X-Y controllable pitch PnP module: Various product requirements are accommodated flexibly.
• Highly effective output: Up to 16K for enhanced production efficiency
• Expandable diversified optional features: Satisfy different application needs

• Supports simultaneous testing of 32 sites.
• Temp: 50~130℃（Option 175℃）
• Contact Force: 480Kg（Option 640Kg）
• Supports larger-size test boards
• X-Y controllable pitch PnP module: Various product requirements are accommodated flexibly.
• Highly effective output: Up to 16K for enhanced production efficiency
• Expandable diversified optional features: Satisfy different application needs

• Site: 8 Sites
• Temp: -55~130℃（Option 175℃）
• Cooling Method：Refrigerant Cooling System

• The built-in ATC5.1 active temperature control system is capable of inhibiting even higher watts.
• Contact force : 240Kg(Option 480 kg)
• The refrigerant cooling technology, compared to liquid nitrogen cooling, is a more cost-effective solution.
• COK is completely compatible with prior triple-temperature models (such as HT-1026 and HT-1028).
• The independent temperature control system detects the temperature at each site and makes adjustments accordingly.
• Simple operating system interface.
• It is easy to install and maintain.

• Site: 8 Sites
• Temp: -55~130℃（Option 175℃）
• Cooling Method：Refrigerant Cooling System

• The built-in ATC5.3 active temperature control system is capable of inhibiting even higher watts.
• Contact force is increased to 480 kg.
• The refrigerant cooling technology, compared to liquid nitrogen cooling, is a more cost-effective solution.
• COK is completely compatible with prior triple-temperature models (such as HT-1026 and HT-1028).
• The independent temperature control system detects the temperature at each site and makes adjustments accordingly.
• Simple operating system interface.
• It is easy to install and maintain.

• Site: 32 Sites
• Temp: -55~130℃（Option 175℃）
• Cooling Method：Refrigerant Cooling System

• Built-in ATC5.1 active temperature control system.
• Contact : Max 480 kg.
• The refrigerant cooling technology, compared to liquid nitrogen cooling, is a more cost-effective solution.
• COK is completely compatible with prior triple-temperature models (such as HT-1026 and HT-1028).
• The independent temperature control system detects the temperature at each site and makes adjustments accordingly.

• Site: 32 Sites
• Temp: -55~130℃（Option 175℃）
• Contact : Max 480 kg
• Cooling Method：Air Cooling System
• Active Thermal Control System ATC 6.1 .
• Independent floating SLK: The independent floating unit offers even greater contact performance.
• Bottom transmission tray: The bottom tray arm is designed to reduce the waiting time between the tray arm and the input arm.
• 16-site suction/placement module: The new suction and placement module design features 16 sites and automatic X-Y spacing to ensure high-throughput of UPH.
